MECHANICAL
SCAN PERFORMANCE
Dimensions: 6 2 x 169 x 82 mm (2.4" x 6.6" x 3.2")
Weight: 130g (4.6 oz)
Scan Pattern:
Area Image
(1280 x 800 pix el array)
Input Voltage: 4.0 to 5.5 VDC
Scan Angle:
Symbol Contrast: 25% minimum reflectance
Horizontal 47°; Vertical 30°
Operating Power: 2.00 W (400mA @ 5 VDC)
Standby Power: 0.45 W (90mA @ 5 VDC)
Interface: USB
difference
Pitch, Skew, Tilt:
±60°, ±70°, 360°
Motion Tolerance: Up to 13cm (5 inch) per second
on 13mil UPC-A Symbol
Decode Capability: All standard 1D, PDF417, and
ENVIRONMENTAL
Operating Temperature¹: 0°C to 50°C (32°F t o 122°F)
Storage Temperature: -20°C to 70°C (-4°F t o 158°F)
Humidity: 5% to 95% relative humidity, non-condensing
Drop: Designed to withstand 30 1.5m (5’) dr ops to concrete
Environmental Sealing: IP42
2
D symbologies (including high
resolution)
3 year factory warranty
Warranty:
