| Features |
|
|
|
|
| > 25 Language |
| > Full ASCII character editing |
| > Dynamic fuzzy decoding |
| > Anti-short circuit design，Contact status indication |
| PARAMETER |
|
|
|
| > Working current：3.3V*50mA (idle:0mA) |
| > Communication distance：≤100m |
| > Storage：16M=8192 (characters/barcode≤128) |
| > Working time ：3 to 10 days |
| > Charging power：5V-400 mA |
| > Light source：650±20nm VLD |
| > Scanning type ：bi-directional |
| > Decoding accuracy：≥3mil@PCS90% Code39 |
| > Scan Width：300mm |
| > Decoding speed：300/sec |
| > Printing Contract：≥20% |
| > Scanning angle：rotation±30°，inclination± 45°，declination ± 60° |
| > Anti-interference：No influence working under strong light and sunshine |
| > Decode Ranges：3mil |
5mm-150mm |
|
| |
10mil |
5mm-100mm |
|
| |
15mil |
30mm-550mm |
|
| |
30mil |
30mm-850mm |
|
| > Decode Capability : UPC/EAN、ISBN、ISSN、Code39、Code 39Full ASCII、 |
| Code32、 Code128、Code11、Code93、Coda bar、 |
| industrial 2 of 5、Interleaved 2 of 5、MSI、GS1 Data Bar. |
| > Indication：Buzzer & LED |
| > Trigger Mode：Button，Continuous |
| > Button life ：1000,000 times |
| > Laser life：10000 hours |
| > Drop test ：1.8m |
| > Base-Interface：USB, USB-COM, RS232 |
| REGULATORY |
|
|
|
| > CE, FCC, RoHS |
| ENVIRONMENT |
|
|
|
| > Operating Temp. ：-20℃ to 50℃ |
| > Storage Temp. ： -30°C to 60°C |
| > Humidity： 5% – 95% non-condensing |
|
|
